HGM Series Micropowder Grinder

• Place of Origin:

   China

• Type:

  Others

• Genre:

  Machinery & Equipment

• sCode:

  STPR1319710

• Place of Origin:

  China
• HGM series of three-rings and medium-speed micro powder grinder is widely used in making fine powder or ultra-fine powder, and the raw materials should be non-inflammable and non-explosive under the Moh’s hardness less than 6 grade such as limestone, calcite, dolomite, kaolin, bentonite, talc, illite, pyrophillite, barite, meerschaum, fluorite, potash ore, etc. The lifetime of spare parts is relied on the hardness of raw materials, and is lowered once the Moh’s hardness is up to 4-6 grades.

  Features of of HGM series Three-rings and Medium-speed Micro-powder Grinder
  Applications: 325-2500mesh fine powder grinding
  Field of application: Agriculture, biology, construction materials, glass / ceramics, mining, mineralogy, metallurgy
  Feed material: medium-hard, hard, brittle, tough
  Size reduction principle: pressure
  Material of grinding Ring and Rollers: manganese steel, Chromium - molybdenum Alloy
  Dust Filter System: With Bag Dust Filter
  Durability: depending on feed material

  Working Principle of HGM series Three-rings and Medium-Speed Micro-powder Grinder
  The material in the Silo will fall down into the Feeding tube evenly through the Vibrating Feeder, and then fall onto the upper scattering plate, after that will scatter on the gap between the roller and ring. The material into the inner wall of the rollers will be reground, and then fall down onto the lower scattering plate. And the fine powder conforms to the standard will be discharged into the Dispersive Twin-pipe Cyclone Separator, and then be discharged. And the massiveness will enter the grinding wall to be reground. The air current with the dust will enter into the lower part of the Pulse Bag Dust Catcher, and then be discharged through the Rotational Discharging Device after filtering dust.

  Product Advantages of HGM series Three-rings and Medium-speed Micro-powder Grinder
  High efficiency and lower consumption
  Non-bearings and non-bolt in the grinding chamber
  The fineness of final products can be 5μm
  The advanced technology in domestic
  Energy conservation
  Long service life
